Centerless polisher for round product with automatic cycle and semi-automatic adjustment on the diameter.

can be completed with different options for handling to better match the final production requirements with different levels of automation.


ST model is offered in different configurations from single units for metal fabricators to high volumes solutions that can find place by metal serivice centers, pipes or bars manufacturers and  where an high degree of productive capacity is required.




Possible applications are:


- Tubes used for furniture and decoration purposes, to prepar chrome plating or painting.


- Welded tubes  - Cosmetic finishing, satin or mirror polish.


- Small parts polishign and sizing


ST - Available with different transport system and workable range.

Tubes, pipes and bars, bundle to bundle


From 10 to 60 mm  -  From 15 to 114 mm

Length from 250 up to 12.000 mm  (according to transport system)

Tools used:  Grinding belts or polishing wheels.

Dry with dust collector or wet with coolant liquid filtration system.


MODEL

Workable products

Workable dimensioms

Diameters

Length

Tools used

Working conditions

(placeholder)

Alternatives to ST


Model STX  semi-automatic centerless grinder and polisher


Mdel STO heavy grinder. For  a products of big diameter see as alternative.


Model PLS or PLN for in-line polishing
